MOV 14D系列
時間：2019-06-27
浏覽量：1691}
産品詳情
産品介紹
1 寬壓敏電壓範圍 18V~1800V
2 高通流量1000~6000A
3 标準14D封裝 14mm
4 過電壓快速響應 小于25nS
5 可選擇同一電壓，更高浪湧能量器件
具體規格
14D-1
|
Part Number |
Maximum Voltage |
Varistor Voltage |
Clamping Voltage |
Max Peak Voltage(8/20Us) |
Max Energy |
Rated Power |
Typical Cap |
||
|
AC |
DC |
V1.0mA(V) |
IP (A) |
VC (V) |
I(A) |
10/1000Us (J) |
(w) |
@1KHz Pf |
|
|
180KD14 |
11 |
14 |
18(15-21.6) |
10 |
36 |
1000 |
4 |
0.1 |
11100 |
|
180KD14J |
2000 |
7 |
|||||||
|
220KD14 |
14 |
18 |
22(19.5-26) |
10 |
43 |
1000 |
5 |
0.1 |
9100 |
|
220KD14J |
2000 |
8 |
|||||||
|
270KD14 |
17 |
22 |
27(24-31) |
10 |
53 |
1000 |
6 |
0.1 |
7400 |
|
270KD14J |
2000 |
10 |
|||||||
|
330KD14 |
20 |
26 |
33(29.5-36.5) |
10 |
65 |
1000 |
7.5 |
0.1 |
6100 |
|
330KD14J |
2000 |
12 |
|||||||
|
390KD14 |
25 |
31 |
39(35-43) |
10 |
77 |
1000 |
8.6 |
0.1 |
5100 |
|
390KD14J |
2000 |
13 |
|||||||
|
470KD14 |
30 |
38 |
47(42-52) |
10 |
93 |
1000 |
10 |
0.1 |
4300 |
|
470KD14J |
2000 |
17 |
|||||||
|
560KD14 |
35 |
45 |
56(50-62) |
10 |
110 |
1000 |
11 |
0.1 |
3600 |
|
560KD14J |
2000 |
20 |
|||||||
|
680KD14 |
40 |
56 |
68(61-75) |
10 |
135 |
1000 |
14 |
0.1 |
2900 |
|
680KD14J |
2000 |
24 |
|||||||
|
820KD14 |
50 |
65 |
82(74-90) |
50 |
135 |
1000 |
22 |
0.6 |
2400 |
|
820KD14J |
2000 |
27 |
|||||||
14D-2
|
Part Number |
Maximum Voltage |
Varistor Voltage |
Clamping Voltage |
Max Peak Voltage(8/20Us) |
Max Energy |
Rated Power |
Typical Cap |
||
|
AC |
DC |
V1.0mA(V) |
IP (A) |
VC (V) |
I(A) |
10/1000Us (J) |
(w) |
@1KHz Pf |
|
|
101KD14 |
60 |
85 |
100(90-110) |
50 |
165 |
4500 |
28 |
0.6 |
2000 |
|
101KD14J |
6000 |
33 |
|||||||
|
121KD14 |
75 |
100 |
120(108-132) |
50 |
200 |
4500 |
32 |
0.6 |
1700 |
|
121KD14J |
6000 |
40 |
|||||||
|
151KD14 |
95 |
125 |
150(135-165) |
50 |
250 |
4500 |
40 |
0.6 |
1300 |
|
151KD14J |
6000 |
53 |
|||||||
|
181KD14 |
115 |
150 |
180(162-198) |
50 |
300 |
4500 |
50 |
0.6 |
1100 |
|
181KD14J |
6000 |
60 |
|||||||
|
201KD14 |
130 |
170 |
200(180-220) |
50 |
340 |
4500 |
57 |
0.6 |
1000 |
|
201KD14J |
6000 |
70 |
|||||||
|
221KD14 |
140 |
180 |
220(198-242) |
50 |
360 |
4500 |
60 |
0.6 |
900 |
|
221KD14J |
6000 |
78 |
|||||||
|
241KD14 |
150 |
200 |
240(216-264) |
50 |
395 |
4500 |
63 |
0.6 |
830 |
|
241KD14J |
6000 |
84 |
|||||||
|
271KD14 |
175 |
225 |
270(243-297) |
50 |
455 |
4500 |
70 |
0.6 |
740 |
|
271KD14J |
6000 |
99 |
|||||||
|
301KD14 |
190 |
250 |
300(270-330) |
50 |
500 |
4500 |
77 |
0.6 |
670 |
|
301KD14J |
6000 |
108 |
|||||||
14D-3
|
Part Number |
Maximum Voltage |
Varistor Voltage |
Clamping Voltage |
Max Peak Voltage(8/20Us) |
Max Energy |
Rated Power |
Typical Cap |
||
|
AC |
DC |
V1.0mA(V) |
IP (A) |
VC (V) |
I(A) |
10/1000Us (J) |
(w) |
@1KHz Pf |
|
|
331KD14 |
210 |
275 |
330(297-363) |
50 |
550 |
4500 |
85 |
0.6 |
610 |
|
331KD14J |
6000 |
115 |
|||||||
|
361KD14 |
230 |
300 |
360(324-396) |
50 |
595 |
4500 |
93 |
0.6 |
560 |
|
361KD14J |
6000 |
130 |
|||||||
|
391KD14 |
250 |
320 |
390(351-429) |
50 |
650 |
4500 |
100 |
0.6 |
510 |
|
391KD14J |
6000 |
140 |
|||||||
|
431KD14 |
275 |
350 |
430(387-473) |
50 |
710 |
4500 |
115 |
0.6 |
460 |
|
431KD14J |
6000 |
155 |
|||||||
|
471KD14 |
300 |
385 |
470(423-517) |
50 |
775 |
4500 |
125 |
0.6 |
430 |
|
471KD14J |
6000 |
175 |
|||||||
|
511KD14 |
320 |
415 |
510(459-561) |
50 |
845 |
4500 |
125 |
0.6 |
390 |
|
511KD14J |
6000 |
180 |
|||||||
|
561KD14 |
350 |
460 |
560(504-616) |
50 |
925 |
4500 |
125 |
0.6 |
360 |
|
561KD14J |
6000 |
185 |
|||||||
|
621KD14 |
385 |
505 |
620(558-682) |
50 |
1025 |
4500 |
125 |
0.6 |
320 |
|
621KD14J |
6000 |
190 |
|||||||
|
681KD14 |
420 |
560 |
680(612-748) |
50 |
1120 |
4500 |
130 |
0.6 |
290 |
|
681KD14J |
6000 |
200 |
|||||||
14D-4
|
Part Number |
Maximum Voltage |
Varistor Voltage |
Clamping Voltage |
Max Peak Voltage(8/20Us) |
Max Energy |
Rated Power |
Typical Cap |
||
|
AC |
DC |
V1.0mA(V) |
IP (A) |
VC (V) |
I(A) |
10/1000Us (J) |
(w) |
@1KHz Pf |
|
|
751KD14 |
460 |
615 |
750(675-825) |
50 |
1240 |
4500 |
143 |
0.6 |
270 |
|
751KD14J |
6000 |
210 |
|||||||
|
781KD14 |
485 |
640 |
780(702-858) |
50 |
1290 |
4500 |
148 |
0.6 |
260 |
|
781KD14J |
6000 |
220 |
|||||||
|
821KD14 |
510 |
670 |
820(738-902) |
50 |
1355 |
4500 |
157 |
0.6 |
240 |
|
821KD14J |
6000 |
235 |
|||||||
|
911KD14 |
550 |
745 |
910(819-1001) |
50 |
1500 |
4500 |
175 |
0.6 |
220 |
|
911KD14J |
6000 |
255 |
|||||||
|
102KD14 |
625 |
825 |
1000(900-1100) |
50 |
1650 |
4500 |
190 |
0.6 |
200 |
|
102KD14J |
6000 |
280 |
|||||||
|
112KD14 |
680 |
895 |
1100(990-1210) |
50 |
1815 |
4500 |
213 |
0.6 |
180 |
|
112KD14J |
36000 |
310 |
|||||||
|
122D14 |
680 |
990 |
1200(1080-1320) |
50 |
1980 |
4500 |
232 |
0.6 |
160 |
|
122D14J |
6000 |
324 |
|||||||
|
142D14 |
750 |
1140 |
1400(1260-1540) |
50 |
2310 |
4500 |
238 |
0.6 |
150 |
|
142D14J |
6000 |
327 |
|||||||
|
162D14 |
1000 |
1280 |
1600(1440-1760) |
50 |
2640 |
4500 |
243 |
0.6 |
140 |
|
162D14J |
6000 |
331 |
|||||||
|
182D14 |
1100 |
1465 |
1800(1620-1980) |
50 |
2970 |
4500 |
250 |
0.6 |
130 |
|
182D14J |
6000 |
335 |
|||||||
